Picture of STL-150 Picture of STL-150 Picture of STL-150 Picture of STL-150

STL-150

$332.25
PCS Company's Shuttle Top Lock - Matched Set, 1.500" Wide
The actual product may differ slightly from the image displayed on the website.
Product specifications
W Lock Width 1.5000
T Size Across 0.875
C Locking Feature Width 0.5000
D Female Lock Height 0.875
E Male Base Height 0.750
F Locking Feature Length 0.500
R Corner Radius 0.250
SHCS Male 8-32 x 7/8
SHCS Female 8-32 x 7/8
