- Available in three sizes, 20t, 32t, or 55t
- Linear lift design
- Individual traceability number
- Verification of each thread with calibrated gauge
- 600 Torque (Nm)
- Supplied with drilling and fixing screws (DIN 912-12.9)
- Safety factor 4:1
Codipro CSS Central Safety Shackle
PCS Company offers the Codipro CSS Metric Central Lifting Ring. The CSS is a screwable, fixed, center ring designed for linear lifting. The CSS also offers a wide space for the shackle to pass through. See instructions under Resources for further info. Register your Codipro Eyebolt .
Press Enter on a column header to sort the table. Press Enter again to reverse the sort order.
| Item Number | SF 4:1 WLL (t) | Height (mm) | Length (mm) | CAD Files | Price (USD) | Quantity |
|---|---|---|---|---|---|---|
| CSS20 | 20 | 249 | 220 | $1,433.02 | ||
| CSS32 | 32 | 249 | 330 | $2,751.40 | ||
| CSS55 | 55 | 521.5 | 540 | $7,134.43 |
