- Install or replace the High Flow Piston Tube (inner tube) without removing the entire assembly
- Makes mold maintenance easier and installation more positive
- High Flow Tubes ensure maximum flow rates
- Positive adjustment of inner tube assembly
- Threads - NPT
- Unit of Measure - Inch
- Head only
- Made in the U.S.A.
Rear Load Nipple Type Cascade Heads
PCS Company's Rear Load Nipple Type Cascade Heads are to be used with High Flow Piston Tubes. The installation and removal of the piston tube does not require removing the entire assembly from the mold. The mold maintenance is made easier along with the installation of the piston tube more positive.
Press Enter on a column header to sort the table. Press Enter again to reverse the sort order.
| Item Number | Tube Thread (NPT) | Hex Size | In/Out Pipe Size (NPT) | Tube Access Size (NPT) | Use with Piston Tube | Mold Nipple (NPT) | High Flow Tube O.D. | CAD Files | Price (USD) | Quantity |
|---|---|---|---|---|---|---|---|---|---|---|
| 141H-4-RL | 1/8 | 1 | 1/4 | 1/4 | PT18* | 1/4 | 1/4 | $13.29 | ||
| 16H-RL | 1/16 | 3/4 | 1/16 | 1/8 | PT16* | 1/8 | 3/16 | $12.26 | ||
| 181H-RL | 1/16 | 7/8 | 1/8 | 1/8 | PT16* | 1/8 | 3/16 | $12.26 | ||
| 186H-RL | 1/16 | 7/8 | 1/8 | 1/8 | PT16* | 1/8 | 3/16 | $12.92 | ||
| 381H-4-RL | 1/4 | 1 | 1/4 | 3/8 | PT14* | 3/8 | 5/16 | $14.13 |
