- Unit of Measure: Inch
- Better alternative to the common set screw
- Convenient hex key installation
- For use with PCS hard and soft core pins
Core Pin Retainers - Steel
PCS Company's Core Pin Retainers are made of hardened steel. These retainers eliminate the need for back up plates thus reducing labor and tooling costs plus are a better alternative than the common set screw,. Four sizes are available to more closely match the core pin diameter.
Press Enter on a column header to sort the table. Press Enter again to reverse the sort order.
| Item Number | H Head Diameter | Head Thickness | L Overall Length | Hex Size | Recommended Core Pins | T Screw Size | CAD Files | Price (USD) | Quantity |
|---|---|---|---|---|---|---|---|---|---|
| CPR-375 | 0.56 | 0.125 | 0.437 | 0.1875 | 3/32 thru 5/53 Diameter Pins | 3/8-24 | $5.52 | ||
| CPR-500 | 0.68 | 0.125 | .437 | 1/4 | 11/64 thru 9/32 Diameter Pins | 1/2-20 | $5.52 | ||
| CPR-750 | 0.93 | 0.125 | .437 | 3/8 | 5/16 thru 7/16 Diameter Pins | 3/4-16 | $5.52 | ||
| CPR-875 | 1.06 | 0.125 | .437 | 3/8 | 15/32 thru 9/16 Diameter Pins | 7/8-14 | $5.52 |
