Picture of MPA-3137 Picture of MPA-3137 Picture of MPA-3137 Picture of MPA-3137

MPA-3137

$551.63
PCS Company's Multi-Plate Lock / Matched Set
The actual product may differ slightly from the image displayed on the website.
SLX100X137
Product specifications
D Overall Height of Female Insert 1.875
E Base Height of Male Insert 1.375
B1 Mounting Hole Location 0.375
B2 Mounting Hole Spread 2.25
C Locking Feature Width 1.25
F Male Alignment Feature Length 1.13
