- Eliminates galling to Guide Pins
- Case-hardened 58 - 62 Rc
- 2-3 week delivery on standard non-stock items
- Custom sizes available upon request
- Unit of Measure - Millimeters
Metric DIN Guide Pin Bushings - Without Collar
PCS Company's Metric DIN Guide Pin Bushings - Without Collar are case-hardened 58 - 62 Rc and finish ground. Nominal diameters ranging from 9 mm to 42 mm with lengths up to 246 mm.
Press Enter on a column header to sort the table. Press Enter again to reverse the sort order.
| Item Number | D I.D. | E O.D. | L Overall Length | H Head Diameter | T Head Thickness | BL Bearing Length | CAD Files | Price (USD) | Quantity |
|---|---|---|---|---|---|---|---|---|---|
| GDB-ESS-09-009 | 9 | 14 | 9 | 16 | 3 | Full | $6.17 | ||
| GDB-ESS-09-012 | 9 | 14 | 12 | 16 | 3 | Full | $7.03 | ||
| GDB-ESS-09-017 | 9 | 14 | 17 | 16 | 3 | Full | $7.95 | ||
| GDB-ESS-09-022 | 9 | 14 | 22 | 16 | 3 | Full | $8.47 | ||
| GDB-ESS-09-027 | 9 | 14 | 27 | 16 | 3 | Full | $9.14 | ||
| GDB-ESS-09-036 | 9 | 14 | 36 | 16 | 3 | 30 | $11.63 | ||
| GDB-ESS-09-046 | 9 | 14 | 46 | 16 | 3 | 30 | $15.56 | ||
| GDB-ESS-09-056 | 9 | 14 | 56 | 16 | 3 | 30 | $20.61 | ||
| GDB-ESS-09-066 | 9 | 14 | 66 | 16 | 3 | 30 | $23.13 | ||
| GDB-ESS-10-009 | 10 | 14 | 9 | 16 | 3 | Full | $5.76 | ||
| GDB-ESS-10-012 | 10 | 14 | 12 | 16 | 3 | Full | $7.03 | ||
| GDB-ESS-10-017 | 10 | 14 | 17 | 16 | 3 | Full | $7.95 | ||
| GDB-ESS-10-022 | 10 | 14 | 22 | 16 | 3 | Full | $8.47 | ||
| GDB-ESS-10-027 | 10 | 14 | 27 | 16 | 3 | Full | $9.14 | ||
| GDB-ESS-10-036 | 10 | 14 | 36 | 16 | 3 | 30 | $12.15 | ||
| GDB-ESS-10-046 | 10 | 14 | 46 | 16 | 3 | 30 | $15.56 | ||
| GDB-ESS-10-056 | 10 | 14 | 56 | 16 | 3 | 30 | $20.61 | ||
| GDB-ESS-10-066 | 10 | 14 | 66 | 16 | 3 | 30 | $25.48 | ||
| GDB-ESS-14-012 | 14 | 20 | 12 | 25 | 6 | Full | $7.82 | ||
| GDB-ESS-14-017 | 14 | 20 | 17 | 25 | 6 | Full | $8.61 | ||
| GDB-ESS-14-022 | 14 | 20 | 22 | 25 | 6 | Full | $9.40 | ||
| GDB-ESS-14-027 | 14 | 20 | 27 | 25 | 6 | Full | $10.44 | ||
| GDB-ESS-14-036 | 14 | 20 | 36 | 25 | 6 | Full | $13.45 | ||
| GDB-ESS-14-046 | 14 | 20 | 46 | 25 | 6 | Full | $16.82 | ||
| GDB-ESS-14-056 | 14 | 20 | 56 | 25 | 6 | 46 | $21.79 | ||
| GDB-ESS-14-066 | 14 | 20 | 66 | 25 | 6 | 46 | $24.95 | ||
| GDB-ESS-14-076 | 14 | 20 | 76 | 25 | 6 | 46 | $28.17 | ||
| GDB-ESS-14-086 | 14 | 20 | 86 | 25 | 6 | 46 | $32.78 | ||
| GDB-ESS-14-096 | 14 | 20 | 96 | 25 | 6 | 46 | $37.70 | ||
| GDB-ESS-15-012 | 15 | 20 | 12 | 25 | 6 | Full | $7.82 | ||
| GDB-ESS-15-017 | 15 | 20 | 17 | 25 | 6 | Full | $8.61 | ||
| GDB-ESS-15-022 | 15 | 20 | 22 | 25 | 6 | Full | $9.40 | ||
| GDB-ESS-15-027 | 15 | 20 | 27 | 25 | 6 | Full | $10.44 | ||
| GDB-ESS-15-036 | 15 | 20 | 36 | 25 | 6 | Full | $13.45 | ||
| GDB-ESS-15-046 | 15 | 20 | 46 | 25 | 6 | Full | $16.82 | ||
| GDB-ESS-15-056 | 15 | 20 | 56 | 25 | 6 | 46 | $21.79 | ||
| GDB-ESS-15-066 | 15 | 20 | 66 | 25 | 6 | 46 | $24.95 | ||
| GDB-ESS-15-086 | 15 | 20 | 86 | 25 | 6 | 46 | $32.78 | ||
| GDB-ESS-15-096 | 15 | 20 | 96 | 25 | 6 | 46 | $37.70 | ||
| GDB-ESS-18-017 | 18 | 26 | 17 | 31 | 6 | Full | $10.84 | ||
| GDB-ESS-18-022 | 18 | 26 | 22 | 31 | 6 | Full | $11.36 | ||
| GDB-ESS-18-027 | 18 | 26 | 27 | 31 | 6 | Full | $12.03 | ||
| GDB-ESS-18-036 | 18 | 26 | 36 | 31 | 6 | Full | $14.79 | ||
| GDB-ESS-18-046 | 18 | 26 | 46 | 31 | 6 | Full | $17.33 | ||
| GDB-ESS-18-056 | 18 | 26 | 56 | 31 | 6 | Full | $22.18 | ||
| GDB-ESS-18-066 | 18 | 26 | 66 | 31 | 6 | 56 | $25.89 | ||
| GDB-ESS-18-076 | 18 | 26 | 76 | 31 | 6 | 56 | $29.61 | ||
| GDB-ESS-18-086 | 18 | 26 | 86 | 31 | 6 | 56 | $33.30 | ||
| GDB-ESS-18-096 | 18 | 26 | 96 | 31 | 6 | 56 | $37.70 | ||
| GDB-ESS-18-116 | 18 | 26 | 116 | 31 | 6 | 56 | $41.44 | ||
| GDB-ESS-20-017 | 20 | 26 | 17 | 31 | 6 | Full | $10.84 | ||
| GDB-ESS-20-022 | 20 | 26 | 22 | 31 | 6 | Full | $11.36 | ||
| GDB-ESS-20-027 | 20 | 26 | 27 | 31 | 6 | Full | $12.03 | ||
| GDB-ESS-20-036 | 20 | 26 | 36 | 31 | 6 | Full | $14.79 | ||
| GDB-ESS-20-046 | 20 | 26 | 46 | 31 | 6 | Full | $17.33 | ||
| GDB-ESS-20-056 | 20 | 26 | 56 | 31 | 6 | Full | $22.18 | ||
| GDB-ESS-20-066 | 20 | 26 | 66 | 31 | 6 | 56 | $25.89 | ||
| GDB-ESS-20-076 | 20 | 26 | 76 | 31 | 6 | 56 | $29.61 | ||
| GDB-ESS-20-086 | 20 | 26 | 86 | 31 | 6 | 56 | $33.30 | ||
| GDB-ESS-20-096 | 20 | 26 | 96 | 31 | 6 | 56 | $37.70 | ||
| GDB-ESS-20-116 | 20 | 26 | 116 | 31 | 6 | 56 | $48.71 | ||
| GDB-ESS-22-017 | 22 | 30 | 17 | 35 | 6 | Full | $11.62 | ||
| GDB-ESS-22-022 | 22 | 30 | 22 | 35 | 6 | Full | $12.69 | ||
| GDB-ESS-22-027 | 22 | 30 | 27 | 35 | 6 | Full | $13.73 | ||
| GDB-ESS-22-036 | 22 | 30 | 36 | 35 | 6 | Full | $15.30 | ||
| GDB-ESS-22-046 | 22 | 30 | 46 | 35 | 6 | Full | $19.30 | ||
| GDB-ESS-22-056 | 22 | 30 | 56 | 35 | 6 | Full | $23.77 | ||
| GDB-ESS-22-066 | 22 | 30 | 66 | 35 | 6 | Full | $27.44 | ||
| GDB-ESS-22-076 | 22 | 30 | 76 | 35 | 6 | Full | $31.06 | ||
| GDB-ESS-22-086 | 22 | 30 | 86 | 35 | 6 | 76 | $35.00 | ||
| GDB-ESS-22-096 | 22 | 30 | 96 | 35 | 6 | 76 | $41.25 | ||
| GDB-ESS-22-116 | 22 | 30 | 116 | 35 | 6 | 76 | $47.50 | ||
| GDB-ESS-22-136 | 22 | 30 | 136 | 35 | 6 | 76 | $62.24 | ||
| GDB-ESS-24-017 | 24 | 30 | 17 | 35 | 6 | Full | $11.62 | ||
| GDB-ESS-24-022 | 24 | 30 | 22 | 35 | 6 | Full | $12.67 | ||
| GDB-ESS-24-027 | 24 | 30 | 27 | 35 | 6 | Full | $13.73 | ||
| GDB-ESS-24-036 | 24 | 30 | 36 | 35 | 6 | Full | $15.30 | ||
| GDB-ESS-24-046 | 24 | 30 | 46 | 35 | 6 | Full | $19.30 | ||
| GDB-ESS-24-056 | 24 | 30 | 56 | 35 | 6 | Full | $23.77 | ||
| GDB-ESS-24-066 | 24 | 30 | 66 | 35 | 6 | Full | $27.44 | ||
| GDB-ESS-24-076 | 24 | 30 | 76 | 35 | 6 | Full | $31.06 | ||
| GDB-ESS-24-086 | 24 | 30 | 86 | 35 | 6 | 76 | $35.00 | ||
| GDB-ESS-24-096 | 24 | 30 | 96 | 35 | 6 | 76 | $39.13 | ||
| GDB-ESS-24-116 | 24 | 30 | 116 | 35 | 6 | 76 | $51.54 | ||
| GDB-ESS-24-136 | 24 | 30 | 136 | 35 | 6 | 76 | $62.24 | ||
| GDB-ESS-30-027 | 30 | 42 | 27 | 47 | 6 | Full | $12.67 | ||
| GDB-ESS-30-036 | 30 | 42 | 36 | 47 | 6 | Full | $15.30 | ||
| GDB-ESS-30-046 | 30 | 42 | 46 | 47 | 6 | Full | $19.30 | ||
| GDB-ESS-30-056 | 30 | 42 | 56 | 47 | 6 | Full | $23.77 | ||
| GDB-ESS-30-066 | 30 | 42 | 66 | 47 | 6 | Full | $27.71 | ||
| GDB-ESS-30-076 | 30 | 42 | 76 | 47 | 6 | Full | $31.58 | ||
| GDB-ESS-30-086 | 30 | 42 | 86 | 47 | 6 | Full | $35.92 | ||
| GDB-ESS-30-096 | 30 | 42 | 96 | 47 | 6 | Full | $39.93 | ||
| GDB-ESS-30-116 | 30 | 42 | 116 | 47 | 6 | 96 | $51.01 | ||
| GDB-ESS-30-136 | 30 | 42 | 136 | 47 | 6 | 96 | $61.32 | ||
| GDB-ESS-30-156 | 30 | 42 | 156 | 47 | 6 | 96 | $70.85 | ||
| GDB-ESS-32-027 | 32 | 42 | 27 | 47 | 6 | Full | $12.67 | ||
| GDB-ESS-32-036 | 32 | 42 | 36 | 47 | 6 | Full | $15.30 | ||
| GDB-ESS-32-046 | 32 | 42 | 46 | 47 | 6 | Full | $19.30 | ||
| GDB-ESS-32-056 | 32 | 42 | 56 | 47 | 6 | Full | $23.77 | ||
| GDB-ESS-32-066 | 32 | 42 | 66 | 47 | 6 | Full | $27.71 | ||
| GDB-ESS-32-076 | 32 | 42 | 76 | 47 | 6 | Full | $31.58 | ||
| GDB-ESS-32-086 | 32 | 42 | 86 | 47 | 6 | Full | $35.92 | ||
| GDB-ESS-32-096 | 32 | 42 | 96 | 47 | 6 | Full | $39.93 | ||
| GDB-ESS-32-116 | 32 | 42 | 116 | 47 | 6 | 96 | $51.01 | ||
| GDB-ESS-32-136 | 32 | 42 | 136 | 47 | 6 | 96 | $61.32 | ||
| GDB-ESS-32-156 | 32 | 42 | 156 | 47 | 6 | 96 | $70.85 | ||
| GDB-ESS-40-046 | 40 | 54 | 46 | 60 | 10 | Full | $34.46 | ||
| GDB-ESS-40-056 | 40 | 54 | 56 | 60 | 10 | Full | $42.55 | ||
| GDB-ESS-40-066 | 40 | 54 | 66 | 60 | 10 | Full | $47.93 | ||
| GDB-ESS-40-076 | 40 | 54 | 76 | 60 | 10 | Full | $52.86 | ||
| GDB-ESS-40-086 | 40 | 54 | 86 | 60 | 10 | Full | $59.29 | ||
| GDB-ESS-40-096 | 40 | 54 | 96 | 60 | 10 | Full | $66.97 | ||
| GDB-ESS-40-116 | 40 | 54 | 116 | 60 | 10 | Full | $77.03 | ||
| GDB-ESS-40-136 | 40 | 54 | 136 | 60 | 10 | 116 | $87.33 | ||
| GDB-ESS-40-156 | 40 | 54 | 156 | 60 | 10 | 116 | $100.58 | ||
| GDB-ESS-40-246 | 40 | 54 | 246 | 60 | 10 | 116 | $161.18 | ||
| GDB-ESS-42-046 | 42 | 54 | 46 | 60 | 10 | Full | $34.46 | ||
| GDB-ESS-42-056 | 42 | 54 | 56 | 60 | 10 | Full | $42.55 | ||
| GDB-ESS-42-066 | 42 | 54 | 66 | 60 | 10 | Full | $47.93 | ||
| GDB-ESS-42-076 | 42 | 54 | 76 | 60 | 10 | Full | $52.86 | ||
| GDB-ESS-42-086 | 42 | 54 | 86 | 60 | 10 | Full | $59.29 | ||
| GDB-ESS-42-096 | 42 | 54 | 96 | 60 | 10 | Full | $66.97 | ||
| GDB-ESS-42-116 | 42 | 54 | 116 | 60 | 10 | Full | $77.03 | ||
| GDB-ESS-42-136 | 42 | 54 | 136 | 60 | 10 | 116 | $87.33 | ||
| GDB-ESS-42-156 | 42 | 54 | 156 | 60 | 10 | 116 | $100.58 | ||
| GDB-ESS-42-246 | 42 | 54 | 246 | 60 | 10 | 116 | $161.18 |
