DTFX4

$87.77
$65.83
Indexable Insert Assembly, Shifts 0 - 3 & Arrow
The actual product may differ slightly from the image displayed on the website.
UOS0004
Product specifications
Configuration Assembly, Shifts & Arrow
D Body Diameter 4
L Body Length 8
Body Engraving Depth 0.12
K - K.O. Hole Dia 3.0 ~ 3.5
B Center Insert Dia 2.4
F Cen. Ins. Length 7.7
MxP M1.6x0.2
TL - Thread Len. 2.7
Arrow Depth 0.22
