DTEX12

$158.85
Indexable Insert Assembly, Numbers 0 - 9 & Arrow
The actual product may differ slightly from the image displayed on the website.
UOR0012
Product specifications
Configuration Assembly, Numbers 0 - 9 & Arrow
D Body Diameter 12
L Body Length 14
Body Engraving Depth 0.22
K - K.O. Hole Dia 5.0 ~ 10.0
B Center Insert Dia 7.5
F Cen. Ins. Length 13.7
MxP M3.0x0.35
TL - Thread Len. 4.2
Arrow Depth 0.5
Body Indexing 10 Equal Divisions
