DTBX8-26

$129.87
$97.40
Indexable Insert Assembly, Months, Arrow, & Year, 2026
The actual product may differ slightly from the image displayed on the website.
UYM2608
Product specifications
Configuration Assembly, Months, Arrow & Year
D Body Diameter 8
L Body Length 10
Year 26
Body Engraving Depth 0.2
K - K.O. Hole Dia 3.0 ~ 7.0
B Center Insert Dia 5
F Cen. Ins. Length 9.7
MxP M2.3x0.25
TL - Thread Len. 3.2
Arrow Depth 0.4
