Picture of API41-20-17 Picture of API41-20-17 Picture of API41-20-17 Picture of API41-20-17

API41-20-17

$122.61
PCS Company's Angle Pin Insert, 20° angle
The actual product may differ slightly from the image displayed on the website.
Product specifications
C Overall Length 1.875
E Head Diameter 1.812
B Angle 20°
A I.D. 0.7515
D Diameter 1.625
H Flat 0.83
